-40℃~60℃ LiFePO4 Battery Module 12V 24V 36V 48V Price:¥ Id:12V50Ah/12V100Ah Place of origin:CHINA

Online inquiry
Detailed content Specification parameter Download

Provide OEM / ODM services for customized battery modules, including 12V, 24V, 36V, 48V, and other specifications.


FEATURES:

  1. Long Cycle Life

    >4000 cycles @ 80% DOD for effectively lower total cost of ownership

  2. Wide Temperature Range

    Exclusive Aluminum LFP technology enables the battery to operate effectively in temperatures ranging from -40℃ to 60℃, making it ideal for outdoor and remote energy storage applications.

  3. Light Weight

    Lifepo4 batteries provide more wh/kg while also being up to 1/3 the weight of its SLA equivalent.

  4. Provide Customized Service

    POLARSTAR offers customized services, tailoring battery packs with different voltage capacities to meet your project requirements, including 12V, 24V, 36V, 48V and more.


APPLICATIONS:

Lead-acid Battery Replacement, RVs, Golf Carts, Marines,  Electric Vehicles (EVs), Aerospace, Military, Equipment and Emergency Devices, Oceanic and Polar Expeditions, Industrial Automation and Monitoring, Renewable Energy Storage, Consumer Electronics etc.,


POLARSTAR strives to become a leading global provider of ultra-wide temperature range battery solutions, and contribute to the development of green energy.



Model

12.8V50Ah

12.8V100Ah

Battery Type

Aluminum-LFP

Aluminum-LFP

Nominal Capacity

50Ah

100Ah

Nominal Voltage

12.8V

12.8V

Working voltage range

8.8V~14.6V

8.8V~14.6V

Standard charge current

5℃~60℃, 0.5C

5℃~60℃, 0.5C

-30℃~5℃, 0.15C

-30℃~5℃, 0.15C

Standard discharge current

-40℃~60℃, 0.5C

-40℃~60℃, 0.5C

Peak Current

70A

200A

Working temperature range

Charge -30℃~60℃

Charge -30℃~60℃

Discharge -40℃~80℃

Discharge -40℃~80℃

IP Level

IP65

IP65

Dimension

229*138*208mm

330*170*215mm

Weight

About 6kg

About 11.4kg
