-50~60℃ LiFePO4 Cell Prismatic 3.2V50Ah-Shenzhen Polarstar Energy Technology Co.,Ltd

-50~60℃ LiFePO4 Cell Prismatic 3.2V50Ah Id：PL36130152F-50LB Place of origin：CHINA

Online inquiry

Previous Next

Detailed content Specification parameter Download

Ultra-wide Temperature Range Prismatic Lifepo4 Cell 3.2V50Ah

FEATURES:

Wide Temperature Range
Working temperature range -50℃~60℃
Long Life
25℃ charge and discharge cycle life ≥2500 cycles
Low Temperature Cycles
-10℃ charge and discharge
cycle life ≥1000 cycles

APPLICATIONS:

Electric Vehicles (EVs), Aerospace, Military, Equipment and Emergency Devices, Oceanic and Polar Expeditions, Industrial Automation and Monitoring, Renewable Energy Storage, Consumer Electronics

POLARSTAR strives to become a leading global provider of ultra-wide temperature range battery solutions, and contribute to the development of green energy.

Model	PL36130152F-50LB
Capacity	Nominal	50Ah
	Min.	49.5Ah
Internal Impedance	AC(1KHz, SOC40%)	≤0.7mΩ
Voltage	Nominal	3.2V
	Charge Cut-off	3.65V
	Discharge Cut-off	2.0V
Working Temp-range	Charge	-40℃~45℃
		-50℃~60℃
	Discharge
Charge	-40℃~-20℃	5.0A/0.1C
	-20℃~0℃	7.5A/0.15C
	0℃~45℃	25.0A/0.5C
Discharge	-50℃~40℃	25.0A/0.5C
	-40℃~60℃	50A/1C
Maximum continuousdischarge	400.0A/8C
100% DOD Cycle Life	-10℃(0.33C/1C)	≥1000 cycles
		≥2500 cycles
	25±2℃(1C/1C)
Weight	≈1350g
Shipment Voltage	3.15-3.35V
